Overview
Platform scales C315 series is designed for direct trade. It is used wherever fast and precise determination of net weight is required.
The C315 series features an indicator PUE C315 series comprising backlit LCD display.
C315 scales is manufactured using powder coated mild steel profiles, with stainless steel weighing platform.
Scales C315 series is available in dual range version on surcharge.
Datasheet
Maximum capacity [Max]
6 kg
Verification scale interval [e]
2 g
Max readability for non-verified scale
0,2 g
Protection class
IP 65 construction, IP 43 indicator
RS232 Interface
1× standard, 1× option
Power supply
100 – 240 V AC 50/60 Hz and battery
Power consumption max.
5 W
Operation time on batteries
max 8h
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 85% RH no condensation
Construction
mild steel St3S
Weighing pan material
stainless steel AISI304
Weighing pan dimensions
300×300 mm
Packaging dimensions
500×390×410 mm
