HX7 HR Multifunctional Scale

HX7.15.HR3 Multifunctional Scale
This image is for reference only.
HX7.15.HR3 Multifunctional ScaleHX7.15.HR3 Multifunctional Scale
close Exit
This image is for reference only.
HX7.15.HR3 Multifunctional ScaleHX7.15.HR3 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.15.HR3 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0034

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
15 kg
Minimum load
100 g
Readability [d]
5 g
Verification scale interval [e]
5 g
Tare range
-15 kg
Max readability for non-verified scale
0,5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
410×410 mm
Packaging dimensions
670×510×330 mm
Net weight
12,7 kg
Gross weight
16,2 kg
Max number of platforms
2
HX7.15.HR3/5 Multifunctional Scale
This image is for reference only.
HX7.15.HR3/5 Multifunctional ScaleHX7.15.HR3/5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.15.HR3/5 Multifunctional ScaleHX7.15.HR3/5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.15.HR3/5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0042

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
15 kg
Minimum load
100 g
Readability [d]
5 g
Verification scale interval [e]
5 g
Tare range
-15 kg
Max readability for non-verified scale
0,5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
400×600 mm
Packaging dimensions
680×490×230 mm
Net weight
22,5 kg
Gross weight
26,8 kg
Max number of platforms
2
HX7.15.HR4 Multifunctional Scale
This image is for reference only.
HX7.15.HR4 Multifunctional ScaleHX7.15.HR4 Multifunctional Scale
close Exit
This image is for reference only.
HX7.15.HR4 Multifunctional ScaleHX7.15.HR4 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.15.HR4 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0038

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
15 kg
Minimum load
100 g
Readability [d]
5 g
Verification scale interval [e]
5 g
Tare range
-15 kg
Max readability for non-verified scale
0,5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
500×500 mm
Packaging dimensions
840×600×400 mm
Net weight
20,8 kg
Gross weight
25,1 kg
Max number of platforms
2
HX7.15.HR5 Multifunctional Scale
This image is for reference only.
HX7.15.HR5 Multifunctional ScaleHX7.15.HR5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.15.HR5 Multifunctional ScaleHX7.15.HR5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.15.HR5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0046

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
15 kg
Minimum load
100 g
Readability [d]
5 g
Verification scale interval [e]
5 g
Tare range
-15 kg
Max readability for non-verified scale
0,5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
600×600 mm
Packaging dimensions
840×700×400 mm
Net weight
23,9 kg
Gross weight
28,7 kg
Max number of platforms
2
HX7.150.HR3 Multifunctional Scale
This image is for reference only.
HX7.150.HR3 Multifunctional ScaleHX7.150.HR3 Multifunctional Scale
close Exit
This image is for reference only.
HX7.150.HR3 Multifunctional ScaleHX7.150.HR3 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.150.HR3 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0037

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
150 kg
Minimum load
1 kg
Readability [d]
50 g
Verification scale interval [e]
50 g
Tare range
-150 kg
Max readability for non-verified scale
5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
410×410 mm
Packaging dimensions
670×510×330 mm
Net weight
12,7 kg
Gross weight
16,2 kg
Max number of platforms
2
HX7.150.HR3/5 Multifunctional Scale
This image is for reference only.
HX7.150.HR3/5 Multifunctional ScaleHX7.150.HR3/5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.150.HR3/5 Multifunctional ScaleHX7.150.HR3/5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.150.HR3/5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0045

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
150 kg
Minimum load
1 kg
Readability [d]
50 g
Verification scale interval [e]
50 g
Tare range
-150 kg
Max readability for non-verified scale
5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
400×600 mm
Packaging dimensions
680×490×230 mm
Net weight
22,5 kg
Gross weight
26,8 kg
Max number of platforms
2
HX7.150.HR4 Multifunctional Scale
This image is for reference only.
HX7.150.HR4 Multifunctional ScaleHX7.150.HR4 Multifunctional Scale
close Exit
This image is for reference only.
HX7.150.HR4 Multifunctional ScaleHX7.150.HR4 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.150.HR4 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0041

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
150 kg
Minimum load
1 kg
Readability [d]
50 g
Verification scale interval [e]
50 g
Tare range
-150 kg
Max readability for non-verified scale
5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
500×500 mm
Packaging dimensions
840×600×400 mm
Net weight
20,8 kg
Gross weight
25,1 kg
Max number of platforms
2
HX7.3.HR2 Multifunctional Scale
This image is for reference only.
HX7.3.HR2 Multifunctional ScaleHX7.3.HR2 Multifunctional Scale
close Exit
This image is for reference only.
HX7.3.HR2 Multifunctional ScaleHX7.3.HR2 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.3.HR2 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0029

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
3 kg
Minimum load
20 g
Readability [d]
1 g
Verification scale interval [e]
1 g
Tare range
-3 kg
Max readability for non-verified scale
0,2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
250×300 mm
Packaging dimensions
580×320×360 mm
Net weight
10,7 kg
Gross weight
13,2 kg
Max number of platforms
2
HX7.30.HR2 Multifunctional Scale
This image is for reference only.
HX7.30.HR2 Multifunctional ScaleHX7.30.HR2 Multifunctional Scale
close Exit
This image is for reference only.
HX7.30.HR2 Multifunctional ScaleHX7.30.HR2 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.30.HR2 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0032

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
30 kg
Minimum load
200 g
Readability [d]
10 g
Verification scale interval [e]
10 g
Tare range
-30 kg
Max readability for non-verified scale
1 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
250×300 mm
Packaging dimensions
580×320×360 mm
Net weight
10,7 kg
Gross weight
13,2 kg
Max number of platforms
2
HX7.30.HR3 Multifunctional Scale
This image is for reference only.
HX7.30.HR3 Multifunctional ScaleHX7.30.HR3 Multifunctional Scale
close Exit
This image is for reference only.
HX7.30.HR3 Multifunctional ScaleHX7.30.HR3 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.30.HR3 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0035

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
30 kg
Minimum load
200 g
Readability [d]
10 g
Verification scale interval [e]
10 g
Tare range
-30 kg
Max readability for non-verified scale
1 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
410×410 mm
Packaging dimensions
670×510×330 mm
Net weight
12,7 kg
Gross weight
16,2 kg
Max number of platforms
2
HX7.30.HR3/5 Multifunctional Scale
This image is for reference only.
HX7.30.HR3/5 Multifunctional ScaleHX7.30.HR3/5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.30.HR3/5 Multifunctional ScaleHX7.30.HR3/5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.30.HR3/5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0043

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
30 kg
Minimum load
200 g
Readability [d]
10 g
Verification scale interval [e]
10 g
Tare range
-30 kg
Max readability for non-verified scale
1 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
400×600 mm
Packaging dimensions
680×490×230 mm
Net weight
22,5 kg
Gross weight
26,8 kg
Max number of platforms
2
HX7.30.HR4 Multifunctional Scale
This image is for reference only.
HX7.30.HR4 Multifunctional ScaleHX7.30.HR4 Multifunctional Scale
close Exit
This image is for reference only.
HX7.30.HR4 Multifunctional ScaleHX7.30.HR4 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.30.HR4 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0039

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
30 kg
Minimum load
200 g
Readability [d]
10 g
Verification scale interval [e]
10 g
Tare range
-30 kg
Max readability for non-verified scale
1 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
500×500 mm
Packaging dimensions
840×600×400 mm
Net weight
20,8 kg
Gross weight
25,1 kg
Max number of platforms
2
HX7.30.HR5 Multifunctional Scale
This image is for reference only.
HX7.30.HR5 Multifunctional ScaleHX7.30.HR5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.30.HR5 Multifunctional ScaleHX7.30.HR5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.30.HR5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0047

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
30 kg
Minimum load
200 g
Readability [d]
10 g
Verification scale interval [e]
10 g
Tare range
-30 kg
Max readability for non-verified scale
1 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
600×600 mm
Packaging dimensions
840×700×400 mm
Net weight
23,9 kg
Gross weight
28,7 kg
Max number of platforms
2
HX7.6.HR2 Multifunctional Scale
This image is for reference only.
HX7.6.HR2 Multifunctional ScaleHX7.6.HR2 Multifunctional Scale
close Exit
This image is for reference only.
HX7.6.HR2 Multifunctional ScaleHX7.6.HR2 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.6.HR2 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0030

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
6 kg
Minimum load
40 g
Readability [d]
2 g
Verification scale interval [e]
2 g
Tare range
-6 kg
Max readability for non-verified scale
0,2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
250×300 mm
Packaging dimensions
580×320×360 mm
Net weight
10,7 kg
Gross weight
13,2 kg
Max number of platforms
2
HX7.6.HR3 Multifunctional Scale
This image is for reference only.
HX7.6.HR3 Multifunctional ScaleHX7.6.HR3 Multifunctional Scale
close Exit
This image is for reference only.
HX7.6.HR3 Multifunctional ScaleHX7.6.HR3 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.6.HR3 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0033

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
6 kg
Minimum load
40 g
Readability [d]
2 g
Verification scale interval [e]
2 g
Tare range
-6 kg
Max readability for non-verified scale
0,2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
410×410 mm
Packaging dimensions
670×510×330 mm
Net weight
12,7 kg
Gross weight
16,2 kg
Max number of platforms
2
HX7.60.HR3 Multifunctional Scale
This image is for reference only.
HX7.60.HR3 Multifunctional ScaleHX7.60.HR3 Multifunctional Scale
close Exit
This image is for reference only.
HX7.60.HR3 Multifunctional ScaleHX7.60.HR3 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.60.HR3 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0036

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
60 kg
Minimum load
400 g
Readability [d]
20 g
Verification scale interval [e]
20 g
Tare range
-60 kg
Max readability for non-verified scale
2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
410×410 mm
Packaging dimensions
670×510×330 mm
Net weight
12,7 kg
Gross weight
16,2 kg
Max number of platforms
2
HX7.60.HR3/5 Multifunctional Scale
This image is for reference only.
HX7.60.HR3/5 Multifunctional ScaleHX7.60.HR3/5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.60.HR3/5 Multifunctional ScaleHX7.60.HR3/5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.60.HR3/5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0044

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
60 kg
Minimum load
400 g
Readability [d]
20 g
Verification scale interval [e]
20 g
Tare range
-60 kg
Max readability for non-verified scale
2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
400×600 mm
Packaging dimensions
680×490×230 mm
Net weight
22,5 kg
Gross weight
26,8 kg
Max number of platforms
2
HX7.60.HR4 Multifunctional Scale
This image is for reference only.
HX7.60.HR4 Multifunctional ScaleHX7.60.HR4 Multifunctional Scale
close Exit
This image is for reference only.
HX7.60.HR4 Multifunctional ScaleHX7.60.HR4 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.60.HR4 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0040

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
60 kg
Minimum load
400 g
Readability [d]
20 g
Verification scale interval [e]
20 g
Tare range
-60 kg
Max readability for non-verified scale
2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
500×500 mm
Packaging dimensions
840×600×400 mm
Net weight
20,8 kg
Gross weight
25,1 kg
Max number of platforms
2
HX7.60.HR5 Multifunctional Scale
This image is for reference only.
HX7.60.HR5 Multifunctional ScaleHX7.60.HR5 Multifunctional Scale
close Exit
This image is for reference only.
HX7.60.HR5 Multifunctional ScaleHX7.60.HR5 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.60.HR5 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0048

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
60 kg
Minimum load
400 g
Readability [d]
20 g
Verification scale interval [e]
20 g
Tare range
-60 kg
Max readability for non-verified scale
2 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
600×600 mm
Packaging dimensions
840×700×400 mm
Net weight
23,9 kg
Gross weight
28,7 kg
Max number of platforms
2
HX7.15.HR2 Multifunctional Scale
This image is for reference only.
HX7.15.HR2 Multifunctional ScaleHX7.15.HR2 Multifunctional Scale
close Exit
This image is for reference only.
HX7.15.HR2 Multifunctional ScaleHX7.15.HR2 Multifunctional Scale
Availability:
In stock
Estimated shipping date :
5 working days
Price:
Individual pricing
Select
a variant:
HX7.15.HR2 Multifunctional Scalekeyboard_arrow_down
  • HX7.15.HR3 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR3/5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR4 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.15.HR5 Multifunctional Scale
    Max: 15kg | d: 5g
  • HX7.150.HR3 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR3/5 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.150.HR4 Multifunctional Scale
    Max: 150kg | d: 50g
  • HX7.3.HR2 Multifunctional Scale
    Max: 3kg | d: 1g
  • HX7.30.HR2 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR3/5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR4 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.30.HR5 Multifunctional Scale
    Max: 30kg | d: 10g
  • HX7.6.HR2 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.6.HR3 Multifunctional Scale
    Max: 6kg | d: 2g
  • HX7.60.HR3 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR3/5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR4 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.60.HR5 Multifunctional Scale
    Max: 60kg | d: 20g
  • HX7.15.HR2 Multifunctional Scale
    Max: 15kg | d: 5g
Options:
Selectkeyboard_arrow_down
  • None
  • Class III Verification
Selectkeyboard_arrow_down
  • None
  • Dual Weighing Range
emailAsk about the product
Rating:
star star star star star
Code:
WP-122-0031

Overview


The HX7 HR scale is a device comprised of AISI 304 (IP66 / IP68) stainless steel indicator, the PUE HX7, and AISI 316 (IP 68 / 69K) stainless steel weighing platform. The HX7 HR has been designed to operate in challenging conditions, even in places where the platform is exposed to acids.

The 7” colour graphic display and the diode bar graph, which signals current net weight of a load in reference to the scale range or declared min, max thresholds, boost comfort especially in case of piecework where fast and precise presentation of product mass deviation is required with regard to the limit values. Housing back is equipped with hermetic communication interfaces such as RS232, RS485, USB, Ethernet, at your disposal there are also digital inputs/outputs and analogue output. This enables cooperation with external devices such as barcode scanners, printers, external displays, control buttons, light signalling towers, other controlling/signalling devices, systems for automatic process control and superior IT systems.

With use of the bracket you can either place the indicator at any flat horizontal surface, or fix it to the wall adjusting the tilt respectively to suit your needs.
The terminal's software allows carrying out processes such as weighing, parts counting, dosing, labelling, formulations and percent weighing. Indicator’s system of information is based on databases (users, products, weighings, packaging, formulations, customers) and ALIBI memory which guarantees stored data safety.
CE
CE
Verification
Verification
2 years warranty
2 years warranty

Datasheet

Maximum capacity [Max]
15 kg
Minimum load
100 g
Readability [d]
5 g
Verification scale interval [e]
5 g
Tare range
-15 kg
Max readability for non-verified scale
0,5 g
OIML Class
III
Display
7” graphic colour
Protection class
IP 68 construction, IP 66/68 indicator
USB Interface
1× standard, 1× option
ETHERNET Interface
1× standard
EtherNet/IP Interface
1 × option (RJ45)
Profinet Interface
1 × option (RJ45)
RS232 Interface
1× standard, 1× option
RS485 Interface
1× option
IN/OUT Interface
4 IN 4 OUT standard, 12 IN 12 OUT option
Modbus RTU module
1× standard
Analog output module (option)
4-20mA, 0-10V
Power supply
100 – 240 V AC 50/60 Hz
Power consumption max.
25 W
Optional power supply
12-24V DC
Operating temperature
-10 ÷ +40 °C
Storage temperature
-10 ÷ +50 °C
Relative humidity
10% ÷ 80% RH no condensation
Indicator
PUE HX7
Keypad
membrane
Number of buttons
22
Construction
Stal stainless steel AISI316
Weighing pan material
stainless steel AISI316
Weighing pan dimensions
250×300 mm
Packaging dimensions
580×320×360 mm
Net weight
10,7 kg
Gross weight
13,2 kg
Max number of platforms
2
